The company carries out its activities in nine workshops, seven of them are located in Italy, six in Chieti and one in the Port of Ortona, on the Adriatic sea, allowing the direct shipment by sea of the items with no size and weight limitations.
Two of the workshops are located in Romania (Walter Tosto WTB), one in Bucharest and one in Oltenita on the Danube river where a private river port allows to carry out all the logistic operations for river/sea shipping.

      Workshops in Chieti (Italy)

      Number of workshops: 6 – Covered Area : 91.000 sqm – Uncovered Area: 340.000 sqm

       Workshop  Address  Offices Area (sqm)  Covered Area (sqm)  Uncovered Area (sqm)  Total Area (sqm)
       WT1  Via Erasmo Piaggio n.72  100  3.680  4.400  8.180
       WT2  Via Erasmo Piaggio n.62  1.450  8.716  8.716  31.960
       WT3  Via A. Grandi   360  4.925  4.925  44.925
       WT4  Via Erasmo Piaggio n.26  2.054  9.400  9.400  31.640
       WT5  Via Erasmo Piaggio n.54   250 25.540   25.540  88.545
       WT7  Via A. Grandi     9.102  9.102  59.772

      Workshop in Ortona (Italy)

      Walter Tosto owns one sea-front workshop (WT6) directly located in the Ortona Port, on the Adriatic Sea, where 3 quays are present with the following features:

      1. RIVA: Height: 1.60 mt, Water Depth: 6.00 mt
      2. RIVA NUOVA : Height: 2.00 mt, Water Depth: 6.00 mt
      3. NORD NUOVA : Height: 2.00 mt, Water Depth: 7.00 mt

      To date, this workshop has allowed us to complete and ship, in one piece, items with noteworthy dimensions. From here, in fact, it is possible to ship items with up to 15 mt of diameter, up to 100 mt lengths and over 1.500 tons of weight.

      Furthermore, with over 9.000 sqm of covered facilities, Ortona’s three covered spans are each equipped with double overhead cranage with unique lifting capacities. The significant dimensions of our furnace for Post Weld Heat Treatment (29mt x 11mt x 10mt) allows us to minimize the quantity of localized PWHTs, while its “Cooperheat” combustion system assures a more rapid and uniform heating while allowing an accurate control of the overall temperature within the furnace (maximum deviation +5%).

      Walter Tosto WTB Bucarest (Romania)

      Walter Tosto WTB, our subsidiary located in Bucharest, operates mainly in the nuclear components sector. With its covered 25.500 sqm, the workshop is specialized in the manufacturing of critical items with a consolidated history in pressure vessels for the nuclear sector. The company (previously known as Fecne) was acquired by Walter Tosto in 2012, which identified in the factory a high potential opportunity for the continuation of its growth in the nuclear market. The workshop infrastructure is now completely renewed with energy efficient improvements, new machinery equipment and modern facilities for employees.

      Web site

      WTO Oltenita, RomaniaUnder construction

      We own a private River Port in Oltenița where we currently make use of an existing temporary covered facility provided with utilities and water for hydrotest. All logistics are carried out by self-propelled trailers and mobile cranes, and our own access ramps to the river for roll-on and roll-off operations.

      A new workshop (WTO) is under construction with covered area:7.700 sqm and Uncovered area:72.000 sqm

      Walter Tosto aims to place itself among the world’s élite manufacturers of critical items. To achieve this, we are equipped with a wide machine park and innovative technologies, which allow us to internally carry out all the critical activities. As a result, the company is able to manufacture and transport products without weight and size limits.

      Dino 9000

      Dino 9000 is a rolling machine entirely engineered and assembled in-house by our staff and features the following characteristics:
      Press capacity for Vanadio: 9000 Tons
      Thk: 300 x 3600 Length, min
      Dia: 2.200
      Rolling Thk: over 300 mm Cold (subject to material type and width)
      3 rolls with plate rolling machine with geometric adjustment configuration

      Waldrich Coburg

      With a length of over 35 meters and a height of over 10 meters, the Waldrich PowerTech Milling Machine represents a unique item equipment, the largest portal milling machine in the world for its accuracy.
      Nr. of Axis: 5
      Net size: 10m x 10m x 35 m

      Correa Versa

      Correa Versa is a Gantry Milling Machine. It has 5 axes able to machine pieces up to 10,5 m in length, 1,65 m in height and 6,8 m wide with very tight tolerances.

      The welding process is the core of our manufacturing activities.

      Our Welding Department is able to employ the following welding processes:

      Welding Process employed

      Manual

      Automatic

      Shielded Metal-Arc welding – SMAW

      X

      Submerged-Arc Welding – SAW

      X

      Subm.-Arc Weld. with strips – SAW STRIP

      X

      SAW Double Wire – SAW Tandem

      X

      Gas Metal-Arc Welding – GMAW

      X

      X

      Gas Tungsten-Arc Welding – GTAW

      X

      X

      Flux-Cord Arc Welding – FCAW

      X

      X

      Electro Slag Welding – ESW

      X

      Plasma-Arc Welding – PAW

      X

      Robotic welding beam

      Our robotic welding system is able to coordinate 8 axes simultaneously (six of which are anthropomorphic + 2 axes, vertical and horizontal respectively) and allows to coordinate repeatability of 0.1 mm. The robot’s load-bearing structure has been designed to ensure minimal bending at maximum extension. The entire system constitutes a very large work area that allows to arrange pieces to be welded in a circular way around the beam.

      Dimensions

      • Height: 10900mm.
      • Maximum width (with open stabilizer): 3920mm.
      • Maximum length (with X1 / X2 axis extended): 14500mm.
      • Maximum range at the tip (with X1 / X2 axis extended): 1000Kg.
      • Y axis stroke: 7350mm.
      • X axis total stroke “X1 + X2”: 8600mm.
      • Y axis rotation: 0-330 °.

      Welding equipment installed

      The system is currently equipped with a TIG Narrow-Gap welding torch with arc oscillation driven by magnetic field and double-wire filler material.

      Internal Bore Welding

      This particular welding is performed using a gun inserted in the tubesheet hole with a rotating head. With special tools is possible to re-build the seat when is necessary to cut the tube already welded.

      Electro Beam Welding with PRO-BEAM partnership

      For the construction of the Vacuum Vessel, Walter Tosto, with the cooperation of PRO-BEAM, has developed and qualified procedures for the execution of EB welding. EB welding, thanks to the law heat input during the activities, allows a better control of the related deformation.

      The full knowledge and the familiarity with all the existing design codes such as ASME, BS 5500, CODAP, Stoomwelzen, AD Merkblatt and GOST allow us to develop the best design from the mechanical point of view. Furthermore, the in-house presence of FEM experts, together with the several ANSYS licenses, make the Finite Element Analysis a powerful instrument in our hands, for the design of critical parts of the equipment.

      In addition to the mechanical design, Walter Tosto has strong skills in the development of the thermal and fluid-dynamic design of Heat Exchangers for the Oil & Gas and Power industries, starting from Process Data Sheets, ensuring all the required guarantees to our customers.

      Our design activities include:
      • 3D simulations
      • Stress analysis by finite elements methods
      • Fracture mechanics analysis
      • Static analysis in steady and unsteady conditions
      • Fatigue analysis
      • Creep fatigue damage evaluation
      • Thermo-hydraulic design of heat transfer systems

      Design codes and standards

      ASME I ASME III Ed.2007 Add. 2009 ASME VIII Div.1 latest edition
      ASME VIII Div.2 latest edition ASME VIII Div.3 latest edition PD 5500
      AD Merkblatt 2000 VSR STOOMWEZEN
      SELO API 579 – 1 ASME FFS-1 API 620/650/660
      CODAP 2000 CODRES HEI GOST
      IBR TEMA EN 13445
      IBC 2006 UBC 97 ABSA
      ASCE / SEI 7-05 BS 7910-2005 EJMA 9TH Ed.
      EN 1405 ASME B 16.5 ASME B 16.47
      API STD 6A API 934 – 941 NACE MR 0175/ ISO 15156-3
      RCC-M e RCC-MR – nuclear sector EUR (European Utility Requirements) – nuclear sector ABSA

      Main Design Softwares

      Finglow: PD5500 pressure vessels calculation software
      Solid Edge: 3D drawing calculation software
      Pro ENGINEER: parametric 3D drawing program
      CATIA V5 R20: 3D drawing program
      ANSYS: finite element analysis and CFD analysis
      ASPEN Shell & Tube Exchanger Design Rating Software
      Aspen Exchanger Mechanical Design Software
      Sant’Ambrogio: mechanical calculation software for VSR, ASME VIII
      Div. 1 + EJMA expansion joints module
      ASME VIII Div. 2, AD 2000 Merkblatt + expansion joints module, WRC 107/297
      AUTO CAD AUTODESK: 2D drawing program

      Metrology softwares

      New River Kinematics: Spatial Analyzer
      Innovmetric: Polyworks
      Hexagon: Emscon, Tracker Pilot, RDS
      Aberlink: 3D MKIII

      Walter Tosto strongly believes in the importance of research and innovation for its growth and development. Over the last 5 years, in fact, investments in Research & Development totaled a considerable proportion within the total investment plan.
      A significant part of this investment regards innovative tools and techniques and allowed us to experiment new applications.
      For instance, by using laser scanner and laser tracker we are able to perform sophisticated dimensional tests that can be implemented where ultra stringent tolerances are applicable and full recordable data is requested.
      Other innovative techniques employed by our companies are Fully Automatic Orbital Welding, Vibration Stress Relieving, Indirect back gouging measurement and Hot Helium leak testing.
